Ruida RDC6585G CO2 Laser Control System with 8 Axis Motion control Multi-head mutual movement

Name: Ruida RDC6585G CO2 Laser Control System with 8 Axis Motion control Multihead mutual movement
Brand: Ruida
Price: 1 USD

Wholesale Ruida RDC6585G CO2 Laser Control System with 8 Axis Motion control Multi-head mutual movement from china suppliers

Brand Name : Ruida

Model Number : RDC6585G

Certification : CE FCC ROHS

Place of Origin : China

MOQ : 1

Price : Negotiable, contact us

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100 sets/day

Delivery Time : 2-3 work days

Packaging Details : Carton

Adapted laser : CO2 glass tube, CO2 RF tube and UV lasers

Axes : 8

Laser channel : 6

Muilt heads sychronous : Support

Communication : Ethernet, USB and WIFI (optional)

Panel : 5'' color screen + keys

Rotary : Y axis rotation

Firmware : Support the remote upgrade of mainboard and panel program

Size : Panel: L180mm*W140mm*H42.1mm Mainboard: L211.3mm*W136mm*H33.1mm

Software : RDWorksV8, plug-in software RDPlug, virtual printing and RDPlug

language : English/French/Russian/Turkish/German/Spanish and other languages

Contact Now

Ruida RDC6585G CO2 Laser Control System with 8 Axis Motion control Multi-head mutual movement

Description of Ruida laser controller RDC6445GT5

The RDC6585G is a high-performance multi-head laser cutting and engraving controller for CO₂ laser machines, supporting 8-axis motion control, up to 6 laser heads, automatic feeding, and high-speed industrial laser processing.

Parameter	RDC6585G
Adapted laser	CO2 glass tube, CO2 RF tube and UV lasers
Axis	8
Laser Interface	6
Double heads asynchronous	Support
Feeding	U axis feeding, Y and U axes feeding synchronously, sheet feeding/large format segmentation feeding
Communication	Ethernet, USB and WIFI
Panel	5'' touch screen. Support screen lock and the upgrade of boot screen
Rotary processing	Y or U axis rotation mode is optional
Installment encryption	Support
Onboard clock	Support (the system time can be modified.)
Firmware upgrade	Support the remote upgrade of mainboard and panel program
Engaving	Plane engraving, slope engraving and gray engraving
Resume processing after power failure	Support
Software	RDWorksV8, plug-in software RDPlug, virtual printing and RDPlug
Operating system	WinXP, Win7, Win8, Win10, 32-bit or 64-bit
Language	Including Chinese, English, French, Russian, Portuguese, Turkish, German, Spanish, Vietnamese, Korean, and Italian
Operating system	WinXP, Win7, Win8, Win10, 32-bit or 64-bit
Accessories	Wireless handle, RD-APP and RD-WIFI

Key Function

Multi-head synchronous laser control for higher productivity and better material utilization
8-axis motion control system supporting up to 6 laser heads
Independent control of laser power, speed, and processing parameters
Support for automatic feeding systems and large-format laser cutting machines
Real-time display of processing path and system status
Compatible with CO₂ laser tubes, RF lasers, and UV lasers
Supports Ethernet, USB, and optional WiFi communication
Built-in support for RDWorks and LightBurn laser software
Integrated functions including automatic blow, auto-focus, and safety protection
